ספק חומרה A320 בורג הברגה

בית » מוצרים » מחבר שמן וגז » ספק חומרה A320 בורג הברגה

No.51 - בריח משושה מלא הברגה, אגוז, מכבשי כביסה. A193 GR B8C, B8T, B8M

מפרטים

A320 B8M stud bolt
Oxid black, Hot dip galvanized, Cad-plated, Blue PTFE Coated(Blue XYLANE 1014,1424),Teflon

סטנדרט	DIN	ANSI/ASME	GB	JIS	NON-STANDARD
גודל	Dia. M5-M100,1/4 above
חומר	Material Stainless steel, Duplex Steel
כיתה	A2-70,A4-70,A4-80,B8,B8M, B8 Cl2, B8M Cl2
סיום	Plain, Y.Z.P., Black, Z.P.HDG plated,PTFE,CAD PLATED
תעודה	ISO9001:2008 , TS16949
שם	A193/A320 B8,B8M

ASTM A193

Scope

Originally approved in 1936, this specification is heavily utilized in petroleum and chemical construction applications. The ASTM standard covers alloy steel and stainless steel bolting materials for high temperature or high pressure service. This specification includes fasteners intended for use in pressure vessels, valves, flanges, and fittings. Although, this material is often available in national coarse (UNC) thread pitches, if being used in traditional applications, threads are specified 8 threads per inch (tpi) for diameters above one inch.

Below is a basic summary of a few of the common grades. ASTM A193 covers a number of other standard specifications not covered in this description including B5, B6, and B16.

Recommended coating,

Oxid black, Hot dip galvanized, Zinc plated, Cad-plated, Blue TPFE Coated(Blue XYLANE 1014,1424), Green TPFE Coated(Green XYLANE 1014,1424).FEFLON coated

Grades

B7	Alloy steel, AISI 4140/4142 quenched and tempered
B8	Class 1 Stainless steel, AISI 304, carbide solution treated.
B8M	Class 1 Stainless steel, AISI 316, carbide solution treated.
B8	Class 2 Stainless steel, AISI 304, carbide solution treated, strain hardened
B8M	Class 2 Stainless steel, AISI 316, carbide solution treated, strain hardened

תכונות מכאניות

כיתה	גודל	Tensile ksi, min	Yield, ksi, min	Elong, %, min	RA % min
B7	Up to 2-1/2	125	105	16	50
	2-5/8 - 4	115	95	16	50
	4-1/8 - 7	100	75	18	50
B8 Class 1	All	75	30	30	50
B8M Class 1	All	75	30	30	50
B8 Class 2	Up to 3/4	125	100	12	35
	7/8 - 1	115	80	15	35
	1-1/8 - 1-1/4	105	65	20	35
	1-3/8 - 1-1/2	100	50	28	45
B8M Class 2	Up to 3/4	110	95	15	45
	7/8 - 1	100	80	20	45
	1-1/8 - 1-1/4	95	65	25	45
	1-3/8 - 1-1/2	90	50	30	45

Chemical Properties

אלמנט	B7 (AISI 4140)	B8 (AISI 304)	B8M (AISI 316)
Carbon	0.37 - 0.49%	0.08% max	0.08% max
Manganese	0.65 - 1.10%	2.00% max	2.00% max
Phosphorus, max	0.035%	0.045%	0.045%
Sulfur, max	0.040%	0.030%	0.030%
Silicon	0.15 - 0.35%	1.00% max	1.00% max
Chromium	0.75 - 1.20%	18.0 - 20.0%	16.0 - 18.0%
ניקל		8.0 - 11.0%	10.0 - 14.0%
Molybdenum	0.15 - 0.25%		2.00 - 3.00%

Recommended Nuts and Washers

Bolt Grade	אגוזים	מכבסים
B7	A194 Grade 2H	F436
B8 Class 1	A194 Grade 8	SS304
B8M Class 1	A194 Grade 8M	SS316
B8 Class 2	A194 Grade 8	SS304
B8M Class 2	A194 Grade 8M	SS316
